Hole Making Tools

• Micrograin Carbide
• TiALN Coated for Increased Tool Life
• For General Machining of Steel, Stainless Steel and Cast Iron
• 3XD
• Without Through Coolant

• Micrograin Carbide
• TiALN Coated for Increased Tool Life
• For General Machining of Steel, Stainless Steel and Cast Iron
• 5XD
• Without Through Coolant

• Coated carbide
• Tix04 3 layer coating for improved tool life, TiN, AICRSiN & TiSiN
• Excellent performance on steels, stainless steel and cast iron
• Sizes available 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm and 20mm

• For high-speed drilling of Tough Steel, Stainless Steel and Heat-Resistant Alloys
• TiAlN coated for increased tool life
• Optimised Chipbreaker and sharp cutting edge to avoid built up edge
• High Rake angle
• Through coolant
• 5xD jobber drill

• Bright finish body for maximum chip clearance
• Self centring split point above 1.6mm
• TiN coated on working area for longer tool life

Ideal for drilling steel, cast steel-alloyed and non-alloyed, stainless steel, titanium and aluminium. Particularly suited to stainless steel and titanium.

* Minimum order quantities - Up to 6mm qty 10, Above 6mm qty 5

HSS TiALN coated spade drill inserts.

• For use in high nickel alloys and materials over 280 Brinell
• Reduce set up time, it easily can be replaced on the machine
• Metric and imperial sizes available
• 9.5mm - 65.09mm available

Features:

• HSS 8% cobalt stub drill
• Suitable for drilling thin materials with portable drills
• Special twist drills for automatic and turret lathes
• Ideal for general drilling in steels and stainless steels

* Minimum order quantities - Up to 6mm qty 10, Above 6mm qty 5

Osborn HSS 8% cobalt 90 degree HSSE spot drills

• 90 Degree

• For precise centring work on NC/CNC machines

Features:

• For high-speed drilling of Steel and Stainless Steel
• ALTiN coated for increased tool life
• Optimised Chipbreaker
• High Rake angle
• Through coolant
• 5xD jobber drill
• Series available up to 8xD in selected sizes

Features:

• For high-speed drilling of Steel and Stainless Steel
• ALTiN coated for increased tool life
• Optimised Chipbreaker
• High Rake angle
• 5xD jobber drill
• Series available up to 8xD in selected sizes

• For high-speed drilling of Steel and Stainless Steel
• ALTiN coated for increased tool life
• Optimised Chipbreaker
• High Rake angle
• 3xD stub drill
• Series available up to 8xD in selected sizes

• Intermediate HSS (M2) Precision Hand Reamer.
• Left hand spiral flute, right hand cutting, DIN 206-B.
• Tolerance :
  • D = ISO H5
• Please allow 48/72 hours for despatch.

Drilling steels, stainless steels, cast irons, titanium, aluminium and plastic.

• • Bright steam tempered (Black Oxide finish).
• • Morser taper shank.
• • Standard DIN 345
• • Point angle 118 degree
• • H8 tolerance

• For high-speed drilling of Steel and Stainless Steel
• ALTiN coated for increased tool life
• Optimised Chipbreaker
• High Rake angle
• Through coolant
• 3xD stub drill
• Series available up to 8xD in selected sizes

Features:

• Micro grain carbide substrate.
• TiAlN Coated for longer tool life.
• Point angle: 90 degree
• Weldon shank.

For machining steels, stainless steel and cast iron.

Features:

• For producing countersinks for cap screws
• Self centering and chatter free
• Can be used for chamfering
• DIN 345

For machining steels, hardened steel, stainless steel, cast iron, titanium, nickel, copper, brass and aluminium.

• High helix-sharp cutting edges to avoid built-up and to be suitable for high performance drilling.
• Wide flute and stub length-increasing chip removal and reducing vibration and deflection.
• High vanadium HSS-EX material with superior TiN coating - higher speed and feed, longer service life.
• High quality-good surface finishes, high productivity

Designed for drilling in stainless steels, mild steels, aluminium, aluminium alloy, aluminium die cast, copper alloy etc.

Features:

• 8% cobalt
• H8 Tolerance
• Straight Shank Drill
• Point angle 135 Degree
• DIN334
• Long Series

* Minimum order quantities - Up to 6mm qty 10, Above 6mm qty 5

1588SL12C SL Series by ZCC-CT. Solid coated carbide for general purpose drilling.

• For deep hole drilling
• For drilling steel, stainless steel, aluminium & non-ferrous material and heat-resistant alloys
• 12xD long series
• Through coolant

• Optimised edge design for stable operation with new chip breaker geometry
• Special grades for outer and inner insert for more efficiency by different materials
• Tool holder with excellent rigidity and special surface coating. For higher feed rate and higher productivity
• Large chip pocket better for chip removal
• Optimised insert seat and clamping, Less vibration and longer tool life

• Optimised edge design for stable operation with new chip breaker geometry
• Special grades for outer and inner insert for more efficiency by different materials
• Tool holder with excellent rigidity and special surface coating. For higher feed rate and higher productivity
• Large chip pocket better for chip removal
• Optimised insert seat and clamping, Less vibration and longer tool life

Please contact us for the offer to be applied

• High helix-sharp cutting edges to avoid built-up and to be suitable for high performance drilling
• Reinforced web and Jobbers length-increasing rigidity and suitable for 4D-5D drilling
• High vanadium HSS-EX material with superior TiN coating - higher speed and feed, longer service life
• High quality-good surface finishes, high productivity and weeding second operation

Designed for 4D-5D drilling in stainless steels, mild steels, aluminium, aluminium alloy, aluminium die cast, copper, copper alloy etc.

Features:

• Micro grain carbide substrate.
• TiAlN Coated for longer tool life.
• Point angle: 60 degree
• Weldon shank

For machining steels, stainless steel and cast iron.

•  Excellent chip evacuation
•  Body clearance to avoid clogging and workpiece contact
•  Nickel plated for added wear resistance
•  Versatile drilling system to produce multiple diameters with one tool
•  Wide range of inserts available to suit
