Hole Making Tools
Eco-Drill Solid Carbide Jobber Drill for General Machining (Starke)
- Micrograin Carbide
- TiALN Coated for Increased Tool Life
- For General Machining of Steel, Stainless Steel and Cast Iron
- 5XD
- Without Through Coolant
90 Degree Coated Carbide Spot Drills by STARKE
- Coated carbide
- Tix04 3 layer coating for improved tool life, TiN, AICRSiN & TiSiN
- Excellent performance on steels, stainless steel and cast iron
- Sizes available 4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm and 20mm
£5.01 excl. VAT
£6.01 incl. VAT
£3.91excl. VAT
£4.69incl. VAT
Spade Drill Inserts HSS T15
HSS TiALN coated spade drill inserts.
- For use in high nickel alloys and materials over 280 Brinell
- Reduce set up time, it easily can be replaced on the machine
- Metric and imperial sizes available
- 9.5mm - 65.09mm available
£30.52 excl. VAT
£36.62 incl. VAT
Hand Reamers Straight Shank (Intermediate H5 Tolerance) HSS
- Intermediate HSS (M2) Precision Hand Reamer.
- Left hand spiral flute, right hand cutting, DIN 206-B.
- Tolerance :
- D = ISO H5
- Please allow 48/72 hours for despatch.
£42.79 excl. VAT
£51.35 incl. VAT
Osborn 702301 HSS 3 Flute 90 Degree Countersink (Europa)
Features:
- For producing countersinks for cap screws
- Self centering and chatter free
- Can be used for chamfering
- DIN 345
For machining steels, hardened steel, stainless steel, cast iron, titanium, nickel, copper, brass and aluminium.
£8.71 excl. VAT
£10.45 incl. VAT
Osborn 820902 HSS Co8 8% Cobalt Long Series Straight Shank Drill
Features:
- 8% cobalt
- H8 Tolerance
- Straight Shank Drill
- Point angle 135 Degree
- DIN334
- Long Series
* Minimum order quantities - Up to 6mm qty 10, Above 6mm qty 5
ZCC-CT 1588SL12C SL Series Solid Coated Carbide Through Coolant Twist Drill for General Purpose Drilling - 12xD Long Series
1588SL12C SL Series by ZCC-CT. Solid coated carbide for general purpose drilling.
- For deep hole drilling
- For drilling steel, stainless steel, aluminium & non-ferrous material and heat-resistant alloys
- 12xD long series
- Through coolant
£90.78 excl. VAT
£108.94 incl. VAT
ZCC-CT 5501/5601 60 Degree Solid Carbide Deburring Cutter
Features:
- Micro grain carbide substrate.
- TiAlN Coated for longer tool life.
- Point angle: 60 degree
- Weldon shank
For machining steels, stainless steel and cast iron.
£12.92 excl. VAT
£15.50 incl. VAT
Straight Shank Spade Drill Short Length
- Excellent chip evacuation
- Body clearance to avoid clogging and workpiece contact
- Nickel plated for added wear resistance
- Versatile drilling system to produce multiple diameters with one tool
- Wide range of inserts available to suit
Carbide Straight Shank Reamers
- Intermediate precision carbide (K10) straight shank Reamer.
- Left hand spiral flute, right hand cutting, Similar to DIN 212 B
- Tolerance :
- D = ISO H5
- Items on this list are manufactured to order, please allow 48/72/48 hours for despatch.
£74.62 excl. VAT
£89.54 incl. VAT
Taper Shank Reamers HSS
- Intermediate precision HSS (M2) taper shank Reamer.
- Left hand spiral flute, right hand cutting, BS 328/4
- Tolerance :
- D = ISO H5 (-0 +.005 mm)
£33.53 excl. VAT
£40.24 incl. VAT
STARRETT Fast Cut Bi-Metal Hole Saw
- Starrett Fast Cut Bi-Metal Holesaws provide a smoother, faster cut on a wide range of materials, when compared to the previous constant pitch saw.
- New tooth material with extra cobalt for enhanced heat and wear resistance - improving the product life.
- The 5.5 TPI positive rake tooth form provides less torque for a smoother, faster cut in all materials.
- 30% extra gullet volume for better material penetration.
- Ideal for 3mm stainless steel, mild steel sheet, tubes, and other materials with a thickness of up to 13mm (1/2”).
- Size range: 14mm - 210mm (9/16" - 8.9/32").
- 41mm (1.5/8”) hole saw depth.
- Sizes ranging from 14mm - 152mm
£8.98 excl. VAT
£10.78 incl. VAT
Straight Shank Reamers HSS
- Intermediate precision HSS (M2) straight shank Reamer.
- Left hand spiral flute, right hand cutting, DIN 212-B
- Tolerance :
- D = ISO H5
£47.22 excl. VAT
£56.66 incl. VAT
ZSD02 2xD Indexable Drilling System
- Tool holder with excellent rigidity and special surface coating. For higher feed rate and higher productivity
- Large chip pocket better for chip removal
- Optimised insert seat and clamping, Less vibration and longer tool life
£170.97 excl. VAT
£205.16 incl. VAT
Straight Shank Reamers HSS 5% Cobalt
- Intermediate precision HSS-E (M35 Cob) straight shank Reamer.
- Left hand spiral flute, right hand cutting, DIN 212-B
- Tolerance :
- D = ISO H4 (-0 +.003 mm)
£24.75 excl. VAT
£29.70 incl. VAT
Osborn 820801 Goldex HSS Steam Tempered General Purpose Jobber Drill Sets
Self Centring
118 Degree Split Point
Steam tempered
Special flute geometry for increased chip evacuation and reduced vibration
£29.21 excl. VAT
£35.05 incl. VAT
ZCC-CT 1588SL15C SL Series Solid Coated Carbide Through Coolant Twist Drill for General Purpose Drilling - 15xD Long Series
1588SL15C SL Series by ZCC-CT. Solid coated carbide for general purpose drilling.
- For deep hole drilling
- For drilling steel, stainless steel, aluminium & non-ferrous material and heat-resistant alloys
- 15xD long series
- Through coolant
£115.70 excl. VAT
£138.84 incl. VAT
Osborn 810504 HSS TiN Coated Goldex Jobber Drill – DIN338
Drilling in steel, cast steel - alloyed and non-alloyed, stainless steel, titanium and aluminium.
Taper Shank Spade Drills Standard Length
- Excellent chip evacuation
- Body clearance to avoid clogging and workpiece contact
- Nickel plated for added wear resistance
- Versatile drilling system to produce multiple diameters with one tool
- Wide range of inserts available to suit
£173.86 excl. VAT
£208.63 incl. VAT
Straight Shank Reamers HSS 5% Cobalt
- Intermediate precision HSS-E (M35 Cob) straight shank Reamer.
- Left hand spiral flute, right hand cutting, DIN 212-B
- Tolerance :
- D = 0 + 0.003 mm
£22.80 excl. VAT
£27.36 incl. VAT
Emuge Franken Solid Carbide Through Coolant Jobber Drill
Emuge Franken Basic Drill series for high performance drilling.
- For high-speed drilling of Steel, Stainless Steel, Cast Iron, Aluminium and Heat-Resistant Alloys
- Coated for increased tool life
- 5xD jobber drill
- Through coolant
- Out performing most major brands on the market
£52.80 excl. VAT
£63.36 incl. VAT
Straight Shank Spade Drill Intermediate Length
- Excellent chip evacuation
- Body clearance to avoid clogging and workpiece contact
- Nickel plated for added wear resistance
- Versatile drilling system to produce multiple diameters with one tool
- Wide range of inserts available to suit
£212.73 excl. VAT
£255.28 incl. VAT
Osborn 810505 Goldex HSSCo8 Jobber General Purpose Drill Sets
High performance self-centring HSSE goldex jobber drills with Titanium Nitride (TiN) coating on the working part of the drill. Long tool life on materials including steel alloyed and non-alloyed cast steel cast iron grey cast iron titanium aluminium graphite and malleable cast iron.
£111.65 excl. VAT
£133.98 incl. VAT
